Basic function

•1 fixed wide-angle lens + 2 zoom lenses (in a PTZ camera), combining 3 lenses for hybrid zoom to achieve wide coverage, long-distance viewing, and clear details.

• The PTZ camera quickly moves to the position of interest clicked on the fixed camera's view, showcasing superior linkage monitoring compared to low-end 3-lens systems in the market.

• 6W monocrystalline solar panel for strong supplementary charging, with a built-in 12000mAh lithium battery.

• Built-in microphone and speaker supporting full-duplex two-way audio communication.

• Equipped with a high-performance T23ZN processor for human detection and tracking.

• PIR alarm push notifications with low false alarm rates.

• Supports red and blue alarm lights for synchronized sound and light alerts.

• Supports cloud storage and local TF card storage.

• Compatible with Android/iOS apps, ensuring stable and reliable performance.

• Compact size, low shipping cost, and IP65-rated outdoor waterproofing.

• Easy to install with a 5-meter extension cable for flexible setup, suitable for various installation scenarios.

AI function

Humanoid detection

Enabled to increase human traces, filter motion detection, and reduce false positives

Humanoid tracking

When human detection is enabled, the system tracks the movement trajectory of detected humans.

Product name

Solar-Powered PTZ Zoom Camera

Model

AY-SCW2618-3L

Key parameter

Main control chip

T23ZN

Sensor

1/3″ Image cmos Sensor×3

Video coding

H264/H265

Video resolution

HD:2304*（1296+1269）/15fps;SD:640*（360+360）/15fps

Audio coding

AAC and G.726

Operation system

Linux

Networking mode (optional)

4G LTE

4G modules in different frequency bands are ed according to the region

WIFI

2.4GH(The 5G band is not supported)

Alarm mode

Detection mode

PIR+ motion detection

Maximum detection range

5-8M

ESP Sensor

120°

Alarm mode

App push information or pictures

Night vision

Illuminance

0.001LUX

Night vision mode

Infrared night vision (max 20 meters) + white full color night vision (max 10 meters) mode is optional

Mode control

Switch mode in App

LED

8pcs dual-core leds (infrared + white)

Lens

Fixed camera

2.8mm（120° wide Angle lens）

PTZ camera

4mm + 15mm(5x optical zoom combined with digital algorithms achieves 15x hybrid zoom, enabling a monitoring distance of up to 50 meters.)

Voice

Speaker

Built-in high-volume waterproof speaker

Microphone

Built-in HD waterproof microphone

PTZ

PTZ angle

Horizontal 340 ° Vertical 90°

Storage

Cloud storage

Support, need to pay for value-added services

local-storage

TF card (Max 128G)

Playback

Event list playback and cloud storage playback

Activity recording duration/trigger sleep interval

5S/ Immediately sleep; 10S/ Sleep for 15S; 20S/ Sleep for 30S; Full time recording/no sleep

Set-up net

Qr code scanning + sonic distribution network

APP

UBOX

Power supply

Power supply mode

Battery powered, solar charged

USB charge

Type-c Charging input DC5V 2A

Battery capacity

12000MA （optional）

Solar power

6W

Others

Work environment

Indoor/outdoor

Work temperature

 -20°~60°

Work humidity

≤80%RH
