1. 4G solar alert intelligent hunting camera
2. Built-in 4G module, different modules in different countries
3. 4 watt solar panel with 3m extension cord, built-in 7800mAh batteries,supports quick disassembly and replacement
4. 4. Two-way voice intercom
5. Cloud storage and TF card storage maximum 128G(without TF card)
6. 4G network remote viewing/playback via APP (UCon)
7. Ultra-low power standby, quick wake up in 0.2 seconds
8. PIR sensing +Ai move detection alarm
9. Support picture mode(14MP) or video mode(4MP) can be set 10.3.6mm lens,built-in infrared light , night vision distance 15 meters
11. Support integrated installation and separated installation
Specifications
Model |
AY-SHM6098 |
|
|
Resolution |
4MP |
General |
System |
Linux + RTOS |
Main processor |
Ingenic-T31ZX |
|
Image sensor |
GC4653 |
|
Video pixel |
2560 X 1440/15fps 640 X 360/15fps |
|
Image pixel |
14M |
|
APP operating system |
Android, IOS (APP:UCon) |
|
Video compression format |
H.265 |
|
Audio compression format |
AAC、G.726 |
|
Internet Connection |
4G |
TD-LTE,TD-LTE / LTE FDD TD-LTE / LTE-FDD |
4G version |
CN/ AU/ EU/ JP/ US/ ASEAN (Optional) |
|
SIM card |
Nano SIM |
|
Alarm |
Detection mode |
PIR sensing +Ai move detection alarm |
Detection distance |
0-15M |
|
Detection angle |
95° |
|
Alarm mode |
Realtime calling or push message |
|
Night vision |
Infrared light |
850nm or 940nm is optional |
night vision range |
15M |
|
Voice |
build-in speaker |
3W |
build-in microphone |
voice monitoring distance 15M |
|
Lens |
Lens |
3.6mm |
Lens Angle |
90° |
|
Storage |
Cloud storage |
storage when alarm recording |
Local storage |
TF Card Max 128G |
Power |
Power supply mode |
Solar Panel+ Build in Batteries |
Solar material |
monocrystalline silicon |
|
Solar Energy Power |
4W |
|
Battery |
3pcs 18650 |
|
Operating power consumption |
2.5W |
|
Standby consumption |
0.003W |
|
Other |
Working Environment |
Indoor/outdoor |
Operation Temperature |
-30°~+60° |
|
Humidity |
0%~90%RH |
|
Package |
N.W. |
0.92KG |
Giftbox size |
193*157*101.5MM |
|
Quantity in carton |
16PCS |
|
G.W. |
15.5kg |
|
Carton size |
398*326*413MM |
