★Compact size, light weight and eligible to wear.
★Full HD, recording resolution up to 1920x1080.
★Built-in WiFi module (optional) for video/audio livestreaming.
★Optional Built-in Bluetooth/NFC.
★Enhanced video encoding technology provides crystalimage quality along with 40% off storage occupation.
★Digital microphone + DSP algorithm brings excellentsound quality.
★Built-in 2000mAh Li-Ion Battery, endures about 12hours of continuous video recording at 1080p30.
★0.96” LCD screen showing work status.
★One white high-light LED for auxiliary illumination.
★Magnetic and pin wearing options, convenient and reliable.
★SupportsAES256 data encryption, only authorized users can access encrypted videos.
★Supportshigh-definition video/audio live view, recorded video/audio review and remotecontrol. (Only available for WiFi version)
Model |
AY-MB118 |
|
System |
OS |
Linux version 3.10.14 |
Display |
0.96” LCD screen |
|
Video |
Video input |
1920x1080 FHD image sensor |
Recording resolution |
1920x1080/1280x720 |
|
Recording frame rate |
1080p30/720p30 |
|
Recording |
Video & audio synchronous recording |
|
Audio |
Audio input |
1ch digital microphone input |
Audio compression |
PCM/AAC |
|
Storage |
Data storage |
Built-in 32GB TF card (64~512GB optional) |
Lens |
HOV |
≤114° |
Network Protocol |
WiFi |
Supports live streaming via WiFi (optional) |
Bluetooth |
Supports Bluetooth communication (optional) |
|
NFC |
Supports NFC (optional) |
|
Auxiliary light source |
White light |
Auxiliary illumination |
Software info |
Text overlay |
Supports time, camera ID & personnel ID overlay |
Overwrite |
Supports auto overwrite |
|
Video encryption |
The encrypted video will only be played back via authorized app with password. |
|
Log |
Key operations, setting changes, record ON & OFF, alarms and other information |
|
Management Software |
Remote video management platform |
Supports live view/remote playback/remote control, etc. (optional for WiFi version) |
Power |
Battery capacity |
Built-in 2000mAh Li-Ion Battery |
Working Time |
About 12h of continuous video recording @ 1080p30 |
|
Working environment |
Temperature |
-20--60℃ |
Humidity |
5%~95% |
|
Others |
Wearing method |
Magnetic and pin |
Date/Time |
Supports synchronization with NTP or local PC |
|
Factory Reset |
Factory default |
|
LED Indicators |
Charging/Charge Completed, idle, recording |
|
Size |
52mm*42mm*18.00mm |
|
Weight |
73g |
