Camera

Name

2Mp Outdoor Bullet+Auto tracking PTZ

Size

2.5inch

Chipset

T31+F37

Sensor

1/3 CMOS（F37）

Minimum illumination

0.001Lux @(F1.4,AGC ON) ,0 Lux with IR；

Lens

Wide2.8mm+8mm lens

Angle

horizontal 0°-350°,vertical 0°-90°

IR-cut

Auto

IR distance

About 30M

Audio and Video

Video compression

Smart H.264

standard

Audio compression standard

G.711

Audio

Two way audio

Storage

2ch 1080P storage together

play back

2Ch 1080P play back at the same time


Image resolution

HD:1920X1080 SD:640x360

frame rate

25fps(day)/12fps(night)

Image settings

mirror/flip

BLC

Support

Network settings

Smart alarm

Input：Human detection/movement tracking/movement alert Output：Floodlight light on together

Connecting

Smart configuration, hotspot AP configuration, manual addition

Protocol

Cloud Private Protocol/Standard ONVIF

General function

Dual stream, mirroring, password protection

Interface

Storage

Micro SD Card (Max 128GB) or cloud Storage

Power plug

DC 12V 2A

Reset

Support Tail wire reset

Network

Support RJ45 Network Port（10/100M）

WiFi

WiFi Standared

802.11b/g/n

Frequency

2.4 GHz

Bandwidth

Support 20MHz

Security

64/128-bit WEP， WPA/WPA2， WPA-PSK/WPA2-PSK

Transmission rate

11b:：11Mbps，11g ：54Mbps，11n ：150Mbps

Cloud service

Cloud

Amazon cloud Aws S3

APP

IPC360 Home (App store download)

Cloud storage

Support

Other

Operating Temperature

-10℃~50℃，10%~90%

and Humidity

Power supply

DC12V±10%

Power consumption

12W MAX

Package size

200*200*117MM

Net Weight

1kg

Carton Size

510*410*420MM 16pcs /Carton 16kg/Carton
