Sensor device

Million HD COMS sensor 1/2.9“GC2063

Lens

 wide-angle 3.6mm lens

Perspective

Horizontal 350degree,Vertical 170degree

Video streaming

Main stream 3MP/15fps Substream 640*360/15fps

system

Lite OS

Standby time

About 6 months (wake up 10 times a day, 30S each time)

Day and night conversion

Red IR and White lights support Automatic switch

Infrared distance

850nm infrared, effective distance 15m

Network configuration method

QR code distribution network

PIR human detection

Support PIR detection wake(Max 7M)

Audio

Support Two way audio

Recorde

PIR detection recorde

Network (4G and wfi cannot be together)

WiFi

2.4GHz WIFI802.11b/g/n

4G

Europe or US or Japan（Optional)

Alarm

Passive human body infrared detection

support

Features

Sleep time

15S,30S,60S Adjustable

Voice call

support

Remote wakeup

Support

PIR wake up

Support （Max 7M）

Mobile client

Ubox，ios11.0，android6.0 Above version

System Requirements

Battery

6pcs 18650 battery （Optional）

working temperature

-10℃ ~+60℃

Working humidity

≤80%RH
