Car DVR Home>Products>Car DVR

AY-MDC200K

Product Category:

Car DVR

Product Figure:

  • Features
  • Technical parameters
  • Product Application
* 4K@30fps (Single Channel)
* 1080P + 1080P (Dual Channel)
* Chipset: NT96663
* Sensor: OV4689 + IMX307
* Dual 150° wide angle lens
* 4pcs Infrared lights
* 3.0" IPS screen
* Audio record
* G-Sensor
* WDR Technology
* Motion Detection
* Loop Recording
* Super capacitor
* Optional GPS
* Built-in WiFi

3.0" 16:9 IPS Screen
Provide instant video playback and makes the device efficient for adjusting video output settings.

2.0MP Sony IMX323 CMOS Sensor
With dual Sony Exmor IMX323 CMOS sensor front and inside camera in one unit, AY-MDC200K can capture the road ahead and interior of your vehicle simultaneously with dual 150° wide-angle lens in Full HD 1920x1080P @30fps.

Infrared Lights for Night Vision
4 IR lights compliment the rear facing camera Sony IMX323 sensor with F1.8 6-layer glass lens greatly enhances night vision in car at low light environment. If you set it to AUTO ON/OFF, when low-light conditions are detected, the infrared lights will automatically turn on to support rear image recording, offering you and passengers a higher level of in-car safety.

G-Sensor
In the event of an impact the device will automatically protect the recording stopping the file from being over-written, individual files can also be "protected" when viewed within playback mode.

GPS (Optional)
The video will be recorded with driving route, speed, date and time, which can then be viewed on PC by supplied ANYUAN playback software.

Voice Record
Built-in microphone & speaker to capture high quality audio clear without distortion. Don't want to record voice? Just one press to turn the microphone off.

Loop Recording
Auto starts up and records automatically when the ignition sparks up, loop recording saves the latest videos and overwrites the oldest videos when memory card is full. Supports up to 128GB card max, please format it on the dashcam before use.

Auto LCD OFF
Support auto LCD off timer which enables the LCD off automatically after the recording begins so you won't be disturbed by another glowing rectangle on your windshield, you can also turn this function off if you prefer the LCD stays on.

Super Capacitor
Built-in super capacitor performs more resistant of high/low temperature and longer lifetime than standard battery technology.

Model

AY-MDC200X

Chipset

NT96663

Sensor (Front)

OV4689

Video Resolution (Front)

4K@24fps,2K@30fps,1080P@60fps

Lens (Front)

150° / 6G / F1.8 Aperture

Sensor (Rear)

Sony IMX307

Video Resolution (Rear)

1080P  30fps

Lens (Rear)

150° / 6G / F1.8 Apeture

Lens Rotatable

180°

Infrared Lights

Yes

LCD Screen

3.0" IPS

Touch Panel

X

Video Format

MP4

Max. Memory Card

Micro SD 128GB (not included)

Audio Record

Yes

Auto Start/Stop Recording

Yes

Seamless Loop Recording

Yes

G-Sensor File Protection

Yes

Wide Dynamic Range WDR

Yes

Motion Detection

Yes

Parking Mode

Time Lapse Recording

GPS

Optional

WiFi

Optional

Fatigue Driving Warning

Yes

Language

Multiple languages

Built-in Battery

X

Super Capacitor

2.7V / 7F

Voltage

Input: 12-24V  Output: 5V 2A

Operating Temperature

-20~ 60

Storage Temperature

-25~ 70

Product Size

83 * 79 * 40mm

Product Weight

111g
