RECORDING

Sensor

5MP CMOS

Chipset

Ambarella A7LA50

Top pixel

Up to 32MP (5M/8M/10M/12M/16M/21M/32M)

Video Resolution

Multiple Recording Resolution 1296P(2304x1296)30P / 1920x1080 30p /1280x720 60p /1280x720 30p /848*480 30p / 720x480 30p

Video Format

MP4

Fast forward

2X, 4X, 8X, 16X, 32X, 64X

REW

2X, 4X, 8X, 16X, 32X, 64X

Audio

High Quality Build-in Microphone.

Audio Format

WAV

Water Mark

User ID, Time and date Stamp Imbedded into Video.

Camera

21 Megapixel Camera option with optional burst shot(3 or 5 photos)

Camera Format

JPEG

Snap Shot

Capture Photos During Video Recording

Recording Time

Up to 12 hours battery time

Storage Capacity

16G(32G/64G)

Storage Level

Visual Indicator

Record Led

Red

One Button Recording

Support One Button Recording

Activation prompt

Audible, Visual, and Tactile Vibration Confirm Activation of Record and Stop

Pre-record function

≥10s pre-record.

Post-record function

≥30s post-record

Video quality

Best/better/normal

Video section

5min/10min/15min/30min/45min

Burst

2/3/5/10/15/20 Shot burst picture taking

Red IR switch

Auto/manual

Motion detection

Auto/manual

Audio guide

Support

Chime

Support

GPS

Support (Build-in) optional

Language

Chinese/English/Others(OEM)

Screen protection

30s/1min/3min/5min

Timing photography

5/10 Seconds

Brightness

Low/high

Auto turn off

30s/1min/3min/5min

Key tone

Support

Sound volume

Support

File type

Police control/criminal inspection/public security

Slide

Support

VIDEO/IMAGE REVIEW

LCD Screen

2 inch TFT-LCD High-Resolution Color Display

Audio Playback

Yes

Video Output

HDMI 1.3 Port

Video Transfer

USB 2.0

CAMERA

Recording Angle

Wide Angle 140 degrees

Night Vision

Up to 10 Meters with Visible Face Detection

Waterproof

IP67

Clip

High Quality Metal Clip with 360 degrees Rotation

PTT

Can Connect to Different Types of Radios

BATTERY

Type

Built-in 3500mAH Lithium

Charging Time

180 minutes

Battery Life

11 Hours

Battery Level

Visual Indicator

OTHERS

Unique ID number/unit

Include 5 digit device ID and 6 digit police ID

Password protect

To set an administrator password to allow deletion via software. User can only view the videos but cannot it.

Dimension

96 mm *62 mm *31mm (2.91” * 1.83” *0.93”)

Weight

160g (5.64oz)

Working Temperature

-40~60 degrees Celsius

Storage temperature

-20~55 degrees Celsius

ACCESSORIES

Standard Accessories

USB cable, Charger, Manual, Driver CD, Universal metal clip
