Model

AY-CWS39CB

Image Sensor

1/3" progressive scan CMOS

Horizontal Resolution

1.3Mega pixel

TV system

PAL/NTSC

Effective pixels

1280(H)*960(V)

Minimum Illumination

0.01Lux@(F1.2,AGC ON),0Lux with IR

S/N

≥44dB

Auto Gain Control

Support

Back light compensation

Support

White Balance

AUTO

Digital Noise Reduction

Adaptive digital noise reduction,2D/3D-DNR

Electronic Shutter

AUTO/1/50（1/60）-1（50，000Sec）

Video Output

Follow AHD standard

Image Function

Original/Reverse image

Output Adapter

4P aviation head cable

Lens

2.33mm(1.7mm Optional)，M12*P0.5

IR LEDS Quantity

5 PCS Φ3 LEDS

IR distance

5meters

IP grade

IP68

Operating Temperature/Humidity

-30°C~+70°C/Humidity≤90%(No condensation)

Power Supply

DC12V±10%

Power Consumption

≤1.2W

Dimension

73.7*54*41(mm)
