Vehicle/car camera Home>Products>Vehicle/car camera


Product Category:

Vehicle/car camera

Product Figure:

  • Features
  • Technical parameters
  • Product Application

1. Using 2.0MP 1080P AHD sensor to support high definition video
2. Waterproof grade IP69K
3. Support ICR switching for day and night monitoring
4. Support mirror switch
5. With night vision function, infrared distance is 13m
6. Flexible installation: mounted on rear or either side of vehicles


 Image Device

 1/2.9" COLOR CMOS

 TV System

 25 frames / 30 frames

 Effective Pixels

 1920*1080 pixels

 Sensing Area

 2.9µm x 2.9µm

 Scanning System


 Sync. System




 Minimum Illumination

 0.01 Lux,0 Lux (with IR)



 Video Format


 Video Output


 Gamma Consumption




 S/N Ratio

 Better than 52dB

 White Balance


 Electronic Shutter

 Auto1/25 (PAL), 1/30 (NTSC) ~ 1-50000 Second



Waterproof Standard


 Current Consumption

 Max.280mA(DC12V,w/o heater or Max.550mA (DC12V, with heater

 Power Supply

 DC12V or DC10~32V

 Operation Temperature

 -20℃~+70, RH 95% Max.

 Storage Temperature

 -30℃~+80, RH 95% Max.


 2.8mm/3.6mm (depending on models)

 Lens Angle

 130°/110°(depending on models)
