★Powerful Ambarella A12S3core
★Sensor: OV4689, HDR supported
★1920×1080p 30fps for recording and1280×720p 30fps for 4G liveview
★JPG, max resolution up to 7696×4329 (32million pixels) snapshot
★HOV ≥130° imageangle
★>15 hours 1080p 30fps long time recording(Each body camera comes with 2 batteries)
★ Language: English/Russian
★IP68 waterproofgrade
★Optional GPS, WIFI,3G/4G_LTE
★16GB/32GB/64GB/128GB/256GB built-in TFcard for option
★Each body camera comes with a singledocking station
★ Startup time:<3 seconds ( from poweron to recording)
Operating system |
Operating system |
Linux 3.10.73 |
Booting time |
< 8 s |
|
Language |
English/Russian |
|
Video |
Video input |
1x digital camera for 1080p/720p/360p recording, available for external camera |
Video output |
2” LCD screen |
|
Recording resolution |
1920x1080/1280x720/640x360p |
|
Frame rate |
30fps at 1080p |
|
Record mode |
Record audio and video at the same time |
|
Compression |
H.265/H.264 |
|
Audio |
Audio input |
1x Mic input, support intercom connection with USB |
Compression |
PMC |
|
Audio record |
Supports audio recording |
|
Video process |
Live video resolution |
1920x1080/1280x720/640x360 |
Photograph |
1920x1080-8640x4752p |
|
Snap |
Supports snapping during recording (photo resolution base in recording resolution) |
|
Storage |
Built in 16GB TF card (available for 16-128GB) |
|
Light source |
Flash light |
To increase brightness when you are recording or taking a photo |
Laser |
Fix the view when you record |
|
IR |
Up to 10 meters with visible shape image at night |
|
Two way radio |
Talk back |
Supports two way radio between different devices (only for 4G/3G device) |
Talk back in platform |
Supports two way radio between device and platform (only for 4G/3G device) |
|
Lens |
Lens’s angle |
>125° |
Alarm |
Alarm input |
Supports alarm input and the alarm can be show in platform |
Interface |
USB |
1x USB, for charging, communication with PC, upgrade OS, connect external camera |
Network |
Protocol |
TCP/IP |
3G/4G |
Optional, built in 3G/4G module (LTE FDD/LTE TDD/WCDMA/TD-SCDMA/GSM/CDMA EVDO/CDMA 1x. Note: this could be different with different module.) |
|
wifi |
Optional, supports Wi-Fi connection and AP |
|
GPS |
GPS |
Optional module for BDS/GPS/GLONASS, to record location and speed |
Firmware |
OSD |
Display and record time, license ID, officer ID, location, speed |
Overwrite |
Supported |
|
Play back |
Support play back, file listed by time and alarm |
|
Play speed |
Support from 1/128 to 128 |
|
Pre-recording/post-recording |
Maximum 20S pre-recording and post-recording |
|
Dewarp |
Supports dewarp to make the picture more accurate and realistic |
|
Safe mode |
Need password to enter setting or playback in safe mode |
|
Record encryption |
Supports record encryption, encrypted video can be played in special player |
|
Log |
Record power on/off, setting change, start record, alarm etc |
|
Software |
Player |
Player software, play multiple cameras together, can also play the encrypted file |
CMSV6 |
Used for 4G/3G model only, support live view/live tracking/historical track |
|
Upgrade |
Firmware maintain |
Firmware can be upgrade though USB |
Working condition |
Temperature |
-40 to 60℃ |
Humidity |
40 to 80% |
|
Other |
Time |
Synchronize with GPS, internet, PC |
Dual bit stream |
Two different bit stream for recording and live streaming via 4G/3G |
|
Default |
Can set to default setting |
|
Indicator |
Power, record, snap, audio record |
|
Battery capacity |
2-piece replaceable battery, 2600mAh each, keep NON-4G device running for about 8h, keep 4G device running for about 4.6H |
|
Charging time is about 4H |
||
Backup battery |
60mA (optional, keep device running during switch battery or battery run out) |
|
Size |
88.3*59.8*34.4mm |
|
Wight |
About 165g |
