Camera test:
● 8 inch retina touch screen, 2048*1536resolutions
● H.265 & H .264 IP, 4K video display viamainstream
● 8MP TVI test,3840 x 2160P 15 fps,4xzoom,video record &playback ,coaxial PTZ control & call OSD menu *
● 5MP AHD test, 2560x1944P12.5F/ 20fps, 4xzoom,video record & playback, coaxial PTZ & call OSD menu *
● 8MP CVI test, 3840 x 2160P 12.5/15fps,4xzoom, video record& playback, coaxial PTZ & call OSD menu *
● HD SDI/EX-SDI camera test, support 1080P 50/60FPS *
● 4 channel ONVIF video simultaneous display,4channel display max support 1080P ,single channel display max support 4K
● Rapid ONVIF, Auto log in and display image, testing report
● Chrome browser, test and set Axis camera
● AXIS, Hikvision camera test, enter ONVIF app,input username and password to test
● CVBS camera test and PTZ control
● IPC TEST (Non-ONVIF test), HIK test tool(Hikvision camera), DH test tool (Dahua camera)
● Video level meter, peak video signal level,SYNC signal level, Color bar chroma level measurement
● DC12V/3A power output, camera can be poweredfrom DC 12Votage
● 48V PoE power output power
● Rapid video, just by one key to detect allnetwork cameras and auto display
● Built in Wi-Fi, display image from thewireless camera, WIFI hotspot
● CVBS loop test, the tester send and receivecolor bar generator signal, to check BNC cable
● Enhanced Color bar generator, PAL/NTSCmulti-system color bar video generator
Cable test:
● Improvement cable tester, UTP cable,telephone cable etc order and connectivity test, can save testing report, ifspecial number, need customized
● RJ45 cable TDR test, test cable pair status,length, attenuation, reflectivity, impedance, skew etc
● Cable tracer, search BNC cable, network cableand telephone cable from the mess cables *
Other functions:
● Network tool: Ping, IP scan, Port Flash, DHCPserver, Trace Route
● POE & power information, DC12V& PoEpower and voltage output /input measurement
● Tester Play: Tester, android version mobilephone and PC display at the same time
● Shortcut button, drop-down menu, can Poe power, IP setting, CVBS, LAN info, HDMI IN etc
● HDM input,720×480p /720×576p /1280×720p/1920×1080p /1024×768p/1280×1024p /1280×900p /1440×900p display,record andsnapshot *
● Traffic monitoring, display network port orWIFI connection real-time upload and download speeds and other networkparameters
● Self - software, you can install appswith android version
● Media player, 4K video files and MKV/MP4media files play
● Quick office, quick office app (supportexcel, word, ppt format) doc. editable
● 8GB SD card including
● Display its genuine resolution of the IPcamera images
● Audio in, support record and save theaudio/LED lamp, calculators, music players and other application tools
● 7.4 V /7000mAh Lithium Ion Polymer Battery,after 6~7 hours charging , working time lasts 16 hours
| LCD |
Item series |
AY-TC1206IP-P series |
|
| Size & Display resolution |
New 8 inch touch screen with retina display ,2048*1536 resolution |
||
| Video Mode |
CVBS |
1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt) |
|
| Analog video level meter, peak video signal level, SYNC signal level, Color bar chroma level measurement |
|||
| PTZ control, RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, etc |
|||
| CVBS loop test |
the tester send and receive color bar generator signal, check BNC cable |
||
| IP camera test |
IPC test /IPC viewer /Rapid Video/RTSP /ONVIF |
||
| Rapid Video |
can testing report |
||
| Hik test tool |
pressing just one key to activate hikvision camera , Image test, can modify the user name, password and IP parameters |
||
| Dahua test tool |
Dahua camera test, modify the user name, password and IP parameters |
||
| IP& CVBS test |
IP& CVBS test at the same time, converter test from analog to digital with dual test window |
||
| Coaxial HD test * |
8MP TVI camera test,3840 x 2160P 15 FPS, UTC control/ call OSD menu |
||
| 8MP CVI camera test: 3840 x 2160P 12.5/15 FPS,UTC control d call OSD menu |
|||
| 5MP AHD test,2592 x 1944P 12.5/20FPS, UTC control d call OSD menu |
|||
| HD SDI/EX-SDI camera test ,support 1080P 25/30/50/60 FPS |
|||
| HDMI input |
1 channel HDMI input,support1080P |
||
| Zoom Image |
4x zoom, to enlarge image, Screen snapshot, record ,save ,view and record and play back |
||
| Analog Video out |
color bar generator |
Output one channel PAL/NTSC color bar video signal for testing monitor or video cable |
|
| HDMI output |
1 channel HDMI output, support 1920*1080P |
||
|
|
12V/3A power output |
Output DC12V/3A power out ,supply temporarily power for the camera |
|
| Power output |
PoE power output |
48V PoE power output, max power 24W |
|
| 5V/2A power output |
USB 5V 2A power output, as a power bank |
||
| Cable test |
TDR cable test * |
BNC cable, network cable, telephone cable, RVV cable and elevator cable, cat 5/6 cable’s length and short circuit. measurement range 1.2KM(Built-in cable TDR test port, only for network cable ) |
|
| Cable tracer |
search BNC cable, network cable and telephone cable from the mess cables |
||
| UTP cable test |
Test UTP cable connection status and display on the screen. Read the number on the screen |
||
| RJ45 cable TDR test |
test cable pair status, length, attenuation, reflectivity, impedance, skew etc |
||
| TesterPlay |
screen projection: tester, android version mobile phone and PC display at the same time |
||
| Network test |
Trace route, Link monitor , DHCP server, port flashing , Ping test |
||
| Wi-Fi |
Built in WIFI,speeds150M,display wireless camera image |
||
| Audio test |
1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
||
| Data monitor |
Captures and analyzes the command data from controlling device，also can send hexadecimal |
||
| PoE test |
Measurement POE switch or PSE power supply voltage and cable connection status |
||
| Drop-down menu |
You can PoE power switch ,IP setting, WLAN switch , HDMI IN functions etc in any interface |
||
| External power supply |
DC 12V 2A |
||
| Battery |
Built-in 7.4V Lithium polymer battery, 7000mAh |
||
| Rechargeable |
After charging 6-7 hours, normal working time 16 hours |
||
| Operation setting |
OSD menu, your desired language: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish etc |
||
| Auto off |
1-30 (mins) |
||
| Working Temperature |
-10℃---+50℃ |
||
| Working Humidity |
30%-90% |
||
| Dimension/Weight |
264mm x 182mm x 43mm / 1Kg |
||
| Below functions are customizable，If add any below function into tester, you need pay addition cost |
|||
| M* |
Digital Multimeter :DC and AC voltage measurement, Resistance measurement, Continuity test, Diode measurements, Capacitance measurement |
||
| O* |
Optical power meter, Wavelength：1625,1550nm,1490nm,1310nm,1300nm,850nm, measurement range ,-70 ～ +10 dBm, for optical power testing and Fiber link loss relative measurement |
||
| V* |
Visual fault locator :10mW visual fault locator with 650nm wavelength can emit red laser sources to test multi-mode and single mode fiber's bending and breakage, test range 10KM |
||
| T* |
TDR cable test: BNC cable, network cable, telephone cable, RVV cable and elevator cable, cat 5/6 cable’s length and short circuit. measurement range 1.2KM |
||
| ADH* |
8MP TVI ,8MP CVI ,5MPAHD test |
||
| ADHS* |
8MP TVI ,8MP CVI ,5MP AHD,HD SDI/EX-SDI test |
||
