Features
-Specializedstructure for vehicle: easy assembly and disassembly; lockable angle andanti-vibration;
-Adaptto volatile environments;
-Anti-jamming&lowpower design: avoid vehicle circuit interface; support high temperature onvehicle roof;
-Audioband-pass filter(optional): reduce vibration noise of vehicle engine and frame
-Goodsurveillance solutions for public bus, taxi, school bus, law enforcement,truck, coach, trains&trams.
Specification:
| Image Device |
1/2.9" COLOR CMOS |
| TV System |
25 frames / 30 frames |
| Effective Pixels |
1920*1080 pixels |
| Sensing Area |
2.9µm x 2.9µm |
| Scanning System |
Interlace |
| Sync. System |
Internal |
| Resolution |
1080P |
| Minimum Illumination |
0.01 Lux,0 Lux (with IR) |
| Microphone |
Optional |
| Video Format |
AHD |
| Video Output |
1.1Vp-p，75Ohm |
| Gamma Consumption |
0.45 |
| AGC |
Auto |
| S/N Ratio |
Better than 52dB |
| White Balance |
Auto |
| Electronic Shutter |
Auto1/25 (PAL), 1/30 (NTSC) ~ 1-50000 Second |
| BLC |
Auto |
| Current Consumption |
Max.280mA(DC12V,w/o heater ）or Max.550mA (DC12V, with heater） |
| Power Supply |
DC12V or DC10~32V |
| Operation Temperature |
-20℃～+70℃, RH 95% Max. |
| Storage Temperature |
-30℃～+80℃, RH 95% Max. |
| Lens |
2.8mm/3.6mm (depending on models) |
| Lens Angle |
130°/110°(depending on models) |
